Specification

Principal Dimension

Specification
External Dimension Internal Dimension

Length

12,192mm

Length between end panels

12,172mm

Length between corner posts

11,615mm

Width

2,438mm

Length between end panels

2,374mm

Height (without extension)

2,896mm

Height (without extension)

2,264mm

Height (max extension)

2,264mm

Height (max extension)

3,483mm

Height extension table
Height extension table

Step

External Dimension

Internal Dimension

Width Extension

9' 6" (2,896mm)

7' 5" (2,264mm)

1st Step

10' 6" (3,200mm)

8' 5" (2,568mm)

2nd Step

11' 6" (3,505mm)

9' 5" (2,873mm)

3rt Step

12' 6" (3,810mm)

10' 5" (3,178mm)

4th Step

13' 6" (4,115mm)

11' 5" (3,483mm)


Weight and Others
Weight and Others
6,250 kg
50,000 kg
56,250 kg
216 ton
648 mm (to fold 4 units into 2,591 mm)
CSC, TCT
BV, GL, ABS and KR
Hydraulic Cushioning Cylinder and Coil Spring
슈퍼랙 제원정보 제공
FLATRACK NOMINAL SPECS*
DIMENSION DESCRIPTION 40' SUPERRACK V4.1

L1

INSIDE LENGTH BETWEEN ENDWALL TOP RAILS

11924 mm

W2

INSIDE WIDTH BETWEEN POSTS

2110 mm

H3
(H3 Min~H3 Max)

INSIDE HEIGHT BETWEEN TOP CORNERCASTING AND FLOOR
(H3 Min: INNER POSTS FULLY RETRACTED)
(H3 Max: INNER POSTS FULLY EXTENDED)

Min: 2264 mm
Max: 3483 mm

H4

HEIGHT BETWEEN FLOOR AND BOTTOM CASTING

632 mm

H5

HEIGHT WHEN END WALL FLUSH FOLDED

648 mm

L6

INSIDE LENGTH BETWEEN POSTS REINFORCEMENTS

11615 mm

W7

DECK WIDTH

2374 mm

L8

EXTERNAL LENGTH

12192 mm

H9
(H9 Min~H9 Max)

EXTERNAL HEIGHT
(H9 Min: INNER POSTS FULLY RETRACTED)
(H9 Max: INNER POSTS FULLY EXTENDED)

Min: 2896 mm
Max: 4115 mm

W10

EXTERNAL WIDTH

2438 mm

W11

WIDTH BETWEEN STANCHIONS

2204 mm

H12

CAMBER AT CENTER BEFORE LOADING

50 mm



MAXIMUM GROSS WEIGHT

50,000 KGS

TARE WEIGHT

6,000 KGS

MAXIMUM PAYLOAD

44,000 KGS

END LASHING POINTS (QUANTITY)

4

SIDE LASHING POINTS (QUANTITY)

19

SIDE STAKE POCKETS (QUANTITY)

6

FORKLIFT POCKETS

YES
(EMPTY LIFT ONLY)

STACKABLE QUANTITY

4 PER 8'6"

* The figures on the above table are for user's guidance only.
